JFV - jb Capacitors
| perating Temperature | -40°C~ +100°C |  |
|---|---|---|
| Voltage Rating | 300, 280, 275, 250V.AC | |
| Capacitance Range | 0.001 ~ 2.2 μF | |
| Capacitance Tolerance | std ±10% | |
| Insulation Resistance | I.R≥30,000MΩ (C≤0.33 μF) I.R≥10,000MΩ (C>0.33 μF) |
|
| Dissipation Factor | 0.08% max at 1KHz 20℃ 0.3% max at 10KHz 20℃ |
|
| Dielectric Strength | 1200 VDC for 60 sec. |
- Non-inductive, (UL940V-0) plastic case sealed with epoxy resin.
- Provides interference suppression with CE & TUV and UL approvals.
Спецификация:
