JFP - jb Capacitors
| Operating Temperature | -40℃~ +85℃ |  |
|
|---|---|---|---|
| Rated Voltage | 1000V, 1250V, 1600V, 2000V.DC | ||
| Capacitance Range | 0.001 ~ 0.15uF | ||
| Capacitance Tolerance | ±5%, ±10% | ||
| Dissipation Factor | ≤0.08% (20 , 10KHz) | ||
| Insulation Resistance | ≥30000MΩ (CR≤0.1 μF) ≥3000s (CR>0.1 μF) |
(20 , 1min) | |
- Extended foil, flame retardant epoxy coated.
- Ideal for high AC current applications, such as CRT deflection for R-F generators and pulse-forming networks.
- Coated with flame retardative epoxy resin which provides from humidity and mechanical damage.
- Temperature coefficient is negative and variety linear over the operation temperature.
